See our Resources page for more information on accessories and options for Custom Panels.
color chart
Custom Panel Specifications
- Exposed fastened, low profile panel
36″ panel coverage
Applies over open framing or solid substrate - Trapezoidal rib on 9″ centers
3/4″ bell top trapezoidal rib height
Class 4 Impact Resistance - Gauges: 29ga and 26ga
Minimum roof slope: 3:12
Class A Fire Resistance Rating
All colors are in stock
additional colors not on the color chart:
White Liner
Hess Green
Shale Green
Dark Bronze
Copper Penny
Galvalume
Crinkles: Black, Charcoal, Burnished Slate, Ash Gray
26g Prints: Jadestone, Weathered Zinc, Rustic Copper
Woodgrains: Rough Sawn Cedar Taupe and White, Antique Barn Wood
STORM SHIELD™
A new coating system & steel protectant utilizing proprietary coating technology
- The coating has self-cleaning properties that repel dirt, stain, mold, and mildew
- Reduces cleaning time and effort
- In limited testing, the coating was shown to shed ice and snow
- Helps meet warranty cleaning requirement
- Less permeable – resists water penetration into the coating
- Keeps appearance looking newer
- Improved coating durability protects the surface
- Shields against marring and installation scratches
Circle R Steel, LLC
Directly from the Manufacturer – Quick turn around time!
Your roofing, siding and trim headquarters.
